Straight Single Flight Steel Staircase Detail

Straight Single Flight Steel Staircase Detail

€8,00 EUR
€8,00 EUR
Sale Sold out

DIGITAL CONTENT – INSTANT DOWNLOAD

WHAT'S INCLUDED

DIGITAL CONTENT - INSTANT DOWNLOAD. Your files will be available to download immediately after successful payment.

STRUCTURAL CAD DRAWING .dwg, .dxf, and .pdf delivered in one zip file.

3D Images and models are not included with this purchase.

REFUNDS POLICY

For digital products we generally cannot offer refunds. Refunds can only be considered under specific circumastances. For more details you can read our refund and returns policy HERE

FULL PRODUCT DESCRIPTION

This is a precise detailed structural CAD drawing for a Straight Single Flight Steel Staircase Detail with a concealed tread wooden step. It will be a great addition to your library when designing steel stairs and it will save you a tremendous amount of time instead of designing it from scratch. It is a full comprehensive design detailed drawing including everything needed to fabricate this staircase.

Interior & Exterior design staircase

This staircase could be uses as an interior exposed steel staircase with all structural elements visible as well as an exterior staircase. Staircase has double UPN profile stringers on each side supported onto middle landing IPE profile main beam with concealed wooden steps within the UPN beam height.

Tread step is presented with a wooden plank but can be changed to suit any design ( i.e steel plate, encase concrete step, marble step, glass step etc )

Comprehensive detailed design

This comprehensive drawing provides a clear and detailed representation of the staircase, complete with all necessary connection details. Includes middle landing, top floor main supporting beams connection details and ground floor foundation stringer support detail.

  • Tread step detailing
  • Stringer baseplate floor connection
  • Middle Landing detail support
  • Top floor support detail

The drawing is designed to be adaptable to any design project, ensuring that it can be used across a wide range of construction applications.

Concealed Tread Steps

Concealed treat steps are supported on the sides of the two UPN side stringers using 10mm flat steel plates and are visible from below the beam. Tread step finish is illustrated with a wooden plank 40mm thick but can be altered according to architectural design.

View full details
