Bath Shower Glass Screen

DIGITAL CONTENT - INSTANT DOWNLOAD. Your files will be available to download immediately after successful payment.

REVIT version 2022 and up. Not compatible with older revit versions.

REVIT Family .rfa file

For digital products we generally cannot offer refunds. Refunds can only be considered under specific circumastances. For more details you can read our refund and returns policy HERE

This is a REVIT family generic model for a bath and shower glass screen door. The family is fully parametric with many options to match any design requirement.

Model can be placed on any project as a generic model on any work plane. The user can specify the height offset from the floor level to match any bathtub size and shower tray height. Model can be flipped on both horizontal and vertical axis for correct placement according to the design.

There are options to turn on and off the fixed part attached to a wall, option to turn on and off the inside and outside door handle, all dimensions are fully parametric.

ATTRIBUTES: REVIT VERSION 2022, FAMILY TYPE: GENERIC MODEL, FILE EXTENSION: .rfa

PARAMETERS:

• Fixed Screen Option to tunr on and off
• Fixed Screen Width
• Door Width
• Offset from floor level
• Screen Height
• Glass thickness
• Handle Bar Height
• Hendle Bar Length
• Rectangular and Rounded edge option with radius parameter
• Handle bar inside/outside option
• Swivel door open inside/outside option
• Materials ( frame, glass, hinge, handle, seal strip )

Several ready made family types, ready to be used are included with this purchase.
